IQE is the largest supplier of compound semiconductor epitaxy wafers globally and has the most comprehensive product offering. A significant majority of sales (69% in H116) are generated from the wireless segment, where the company’s wafers are used to make radio frequency chips for use in mobile devices and mobile infrastructure. IQE has more than a 50% share of the wireless market and supplies all the major wireless chip manufacturers. It has reinvested some of the profits from supplying wireless epitaxy for the smartphone boom into creating a platform serving numerous industry verticals. Management sees this driving strong growth over a five- or six-year period. Most immediately, revenues from the photonics segment (17% of H116 revenues) are growing strongly, driven by rising market demand and new applications incorporating innovative technologies. Development work across a broad range of applications including touchless sensing, gesture recognition, non-invasive blood monitoring, CPV (concentrated photovoltaic) solar and power electronics is starting to reach maturity. In addition, IQE has begun to generate its first revenues from IP licencing.

Revenues increased by 18% year-on-year (£9.8m) during H116 to £63.0m. This resulted from modest growth in the wireless segment, strong growth in photonics and a contribution from licence income, (which started generating revenues in H215). Adjusted profit before tax rose by 71% (£4.2m) to £10.1m. Our estimates assume modest growth in wireless revenues, backed by market share gains, compound semiconductor hungry 4G handsets and deployment in new applications such as base stations (in partnership with MACOM). We assume that photonics revenues will continue to grow strongly, driven by rising underlying demand from data centre connectivity, consumer applications, industrial processing and fibre to the premises combined with a switch to outsourcing. We assume licence revenues will be lower in FY16 and FY17 because FY15 benefited from upfront fees, while we model only recurring revenues during FY16 and FY17. We note the potential for stronger growth associated with the deployment of infrared sensors in consumer applications, the adoption of gallium nitride on silicon (GaN-on-Si) in power electronics and volume roll-out of CPV technology.

Although the share price has rallied from a low of 16.25p in June, IQE’s rating still remains undemanding relative to its peers. As the reasons why investors have historically applied a discount have been removed (see pages 13-14 for detailed discussion), the share price has responded positively. Our analysis of peer multiples indicates that there is still some way to go before IQE is trading on similar multiples to its listed peers. Our indicative valuation range of 40-45p puts IQE on multiples that are close to the mean of our sample of listed peers. Further newsflow of photonics growth and stable wireless demand should help close the remaining valuation gap.

While the growth in photonics has substantially diversified the business, 69% of H116 sales were attributable to the wireless segment. IQE’s financial performance remains heavily influenced by the health and inventory cycle of the handset industry. The timing and rate of revenue growth from emerging technologies is difficult to gauge. Sales and earnings are also exposed to changes in the US dollar/sterling exchange rate. The impact is largely translational, with some transactional exposure.

IQE is the largest outsourced supplier of compound semiconductor epitaxy wafers globally. It has the most comprehensive product offer, which encompasses over 100 patents and a rich pool of trade secrets. IQE takes very thin discs of compound semiconductor material up to 150mm in diameter (wafers) and deposits successive thin “epitaxial” layers, each containing different combinations of semiconductors on them. By controlling exactly the thickness and composition of each of the layers deposited on the substrate, IQE is able to provide customised wafers that meet each customer’s precisely defined electrical and optical requirements. These epitaxy wafers are used by manufacturers of wireless chips and optical devices such as laser chips, which carry out further processing steps to create finished devices.

IQE has reached this dominant position with respect to both market share and breadth of product offer through a combination of organic development and acquisition (see Exhibit 1). It has facilities in Europe, the US and Asia, giving it a presence in all three major semiconductor manufacturing regions. IQE employs over 500 people and is headquartered in Cardiff, Wales.

Since its formation in 1999, the majority of IQE’s revenues have been derived from the wireless market. Refinements to the basic technology are driving strong growth in the photonics sector and taking IQE into new application areas such as touchless sensing, gesture recognition, non-invasive blood monitoring, CPV solar and power electronics. However, continued growth of the wireless market itself and capture of share within it means that while the proportion of revenues derived from this segment has reduced (see Exhibit 4), it is still dominant. We expect the proportion of revenues from non-wireless applications to increase further. For example, the formation of JVs in the UK and Singapore delivered the first revenue from licencing IP during FY15. The JVs also form the nuclei of compound semiconductor clusters in which IQE can commercialise the JVs’ academic research, taking novel materials from prototypes to high-volume production for industry partners. The JV formed with Cardiff University in July 2015 is to spearhead a new £150m UK National Catapult centre to develop and build next-generation compound semiconductors, in effect creating a national and European centre of excellence in South Wales.

IQE’s epitaxial manufacturing service is a critical stage of the compound semiconductor supply chain. Its compound semiconductor epitaxial wafer foundries take very thin discs of substrate (compound semiconductor, sapphire or silicon) and deposit a succession of thin layers on them. Up to 300 epitaxial layers may be deposited, each of which may be only a few atoms thick. Each separate epitaxial layer contains a different combination of elements to give specific electrical or optical properties. By precisely controlling the thickness and composition of the layers deposited on the substrate, IQE provides customised epiwafers that meet each customer’s specific electrical and optical requirements. The finished epiwafers are sold to manufacturers of high-frequency chipsets and laser chips, which carry out further processing steps to create finished devices.

Compound semiconductor processing remains a highly specialised field. Semiconductor processing facilities or foundries manufacturing silicon integrated circuits do not have the requisite experience or IP. Until 15 years ago, compound semiconductor chip vendors carried out the epitaxy stage in house, but many have opted to outsource the process, freeing up capital for elsewhere in the business and gaining access to a wider range of technologies. For example, in 2012 RFMD (now part of Qorvo) sold its in-house epitaxy operation to IQE. In 2005 only 20% of compound semiconductor epitaxial wafer manufacture was outsourced; the figure is now over 50%.

Market consolidation means the number of independent compound semiconductor wafer manufacturers worldwide is decreasing. For example, IQE acquired Kopin’s epitaxy activity in 2013 and in February 2015 Sumitomo Chemical acquired Hitachi Metals. In February 2016 semiconductor laser specialist II-VI acquired EpiWorks and in March 2016 Chinese LED manufacturer Sanan Optoelectronics announced its intention to acquire compound semiconductor foundry Global Communication Semiconductors, though the merger agreement was terminated in August. IQE now has the largest share, with over 50% of the non-captive wireless wafer market, an increase from the estimated 10% it held in 2005. The range of product and material processing capabilities it offers is probably the widest in the sector. This capability, together with the ability to offer internal dual sourcing from within the group, has made IQE the market leader.

Compound semiconductors are key enabling materials in a wide range of electronic and optoelectronic systems. Compound semiconductors are necessary for these applications because, unlike silicon, which is a single element semiconductor and therefore has a fixed set of electronic characteristics, compound semiconductors are made from a mixture of elements. By combining elements (gallium, arsenic, indium, phosphorus and aluminium) in different proportions, engineers can make materials with a diverse range of optoelectronic and electronic properties.

While wireless remains IQE’s largest segment (69% of H116 revenues), the company’s longstanding initiatives to drive diversified growth are now starting to bear fruit, with the photonics segment growing 45% year-on-year in H116 and contributing 17% of overall sales. In the same way that IQE was a significant beneficiary of the stellar growth in the mobile phone industry in the past, it is likely to benefit in the future from strong growth for photonics devices. Moreover, since the range of applications within photonics is diverse, encompassing high-speed communications and numerous precision sensing applications, demand is likely to be less volatile than the wireless market, which is dominated by handsets. In the near term, top line performance will be dominated by prospects in wireless and photonics, but successful execution in power electronics could trigger a third wave of significant growth. IQE has also started to generate revenues from IP licensing. This strategy has proved successful, delivering revenue and profits growth during FY15 despite weakness in the wireless sector. In the longer term, this may open up opportunities in markets such as LED lighting where very high volumes of material are required.

Compound semiconductors allow electrons to travel much more quickly in them than in bulk silicon and can handle higher-voltage gradients before breaking down. This enables the creation of much higher-frequency, lower noise and more power-efficient electronic systems, which is important for mobile, satellite and wireless communications applications. In a mobile phone, the memory and data processing chips will be silicon, but the transmit and receive functions will typically be gallium arsenide (GaAs), particularly for higher-specification handsets. This is because GaAs power amplifiers are more efficient than their silicon counterparts and thus provide longer battery time.

According to Strategy Analytics, wireless applications currently account for slightly less than 80% of all GaAs device sales, while cellular terminals account for more than 50%. Consequently, while IQE was a significant beneficiary of the growth in the handset industry, its top line performance has fallen back since the peak in 2013. Overall growth prospects for the wireless GaAs wafer market are complicated by the fact that there are a number of contrasting structural factors at play: the size of the handset market; evolution of more complex smartphones; inventory cycles; price erosion; and chips getting smaller. IQE’s newer GaN-on-Si technology opens up complementary wireless markets including base stations, reducing its dependence on handsets.

In June 2016, market analysts Gartner predicted that worldwide smartphone sales growth would slow to 7% in 2016 (1.5bn units), down from 14.4% in 2015, with a CAGR of 6% between 2016 and 2020. However, the shift to higher-specification handsets requiring greater bandwidths and support for multiple bandwidth and standards will result in a higher average value of RF components per phone year-on-year (see Exhibit 5). This means that the RF market is likely to grow more quickly than the smartphone market. While we caution against making a direct link from RF market statistics to IQE’s prospects by noting that the RF market includes SOI and silicon devices as well as compound semiconductor devices, data published in January 2016 by market research company The Information Network stated that the GaAs IC (Integrated Circuit) market grew by 25% during 2015 on smartphone and the Internet of Things (IoT) momentum. In August 2016 TechNavio, a technology research and advisory company, forecast that the GaAs wafer market would grow at a CAGR close to 13% between 2016 and 2020.

In order to reduce the bill-of-materials cost of mobile devices, handset manufacturers have investigated implementing the power amplifiers on SOI and integrating them with other elements of the RF front end such as the amplifier controller, which historically have been implemented in silicon. For several years most GSM (2G) phones have been using silicon-based power amplifiers but this cheaper material was not suitable for 3G and 4G signals. In February 2013 Qualcomm caused a stir by announcing two SOI power amplifiers for LTE (4G) phones. While some industry pundits claimed that this product introduction showed that SOI would swiftly displace compound semiconductors, causing a collapse in the share price of compound semiconductor stocks including IQE, this gloomy prediction has not been fulfilled. Even Qualcomm now recognises that SOI technology has its limitations. When announcing the formation of a JV with TDK in January 2016, Qualcomm disclosed that it was developing both SOI and GaAs power amplifiers and it has been actively recruiting compound semiconductor experts. Given that the two technologies are likely to continue to co-exist, the important question for IQE is the probable market share for each technology, which determines potential GaAs growth. GaAs’s advantages of performance/power efficiency remain pertinent, especially as phone networks shift to higher frequencies in search of spectrum availability and battery life limitations remain an issue. A report from Strategy Analytics, published in October 2015, stated that despite headwinds from competitive technologies, ie SOI, and price erosion it still expected the GaAs RF device market to grow from an estimated $7bn in 2015 to peak at $8bn in 2018.

The exclusive agreement to licence Translucent’s cREO technology (page 10) puts IQE back on the offensive by providing a potential route to recapture share in the handset antenna switch segment, which has transitioned largely to SOI over the past few years, and to take share in the filter segment. Exhibit 5 shows that the wireless switch, filter and power amplifier markets combined are collectively three to four times the size of the market for wireless power amplifier chips alone. Management note that this technology is at the development phase with a two- to three-year time horizon.

Visibility of underlying demand is obscured by the frequent but irregular inventory build-ups and then correction cycles experienced by customers. There was significant destocking during FY15, which does not appear to have continued into H116.

IQE is currently the dominant supplier globally with over 50% market share. Following the acquisition of Kopin and RFMD’s in-house epitaxy operations, IQE now provides epitaxy services to all the major RF chip suppliers. This reduces its exposure to market share swings, which had previously resulted in revenue volatility.

IQE’s wireless revenues increased by 7% year-on-year during H116 to £43.2m, which is in line with management’s estimates of mid-single-digit market growth. The destocking that characterised H215 has stopped. Our estimates model H2 sectoral sales at similar levels to H116 (IQE no longer feels that the 45/55 H1/H2 split is valid). This is underpinned by the renewal of a long-term supply contract with a premier Tier 1 customer for epiwafer products including power amplifiers, low-noise amplifiers and switches that management estimate will contribute over $55m in revenues in FY16. In addition, IQE is winning a higher proportion of clients’ business and securing business related to new products such GaN on Si devices for base stations (with MACOM). These programme wins are supported by continuous improvements in technical performance.

Based on the Strategy Analytics report discussed earlier, we assume 2% growth in wireless revenues in FY17. This excludes any upside from roll-out of the cREO technology to recapture share in the switch segment.

Compound semiconductors exhibit properties that convert light to electricity and electricity to light extremely efficiently. IQE has developed a range of epitaxial wafers based on two key technologies: vertical cavity surface emitting laser (VCSEL), which is used in data communications, consumer and industrial applications; and indium phosphide (InP), which is used in fibre to the premises (FTTP) and other short-haul optical networks.

VCSELs can modulate signals at frequencies up to and exceeding 25Gbps, so are ideal for high-speed communications and precision sensing applications. They provide reliable operation at distances ranging from close proximity links (centimetres) up to 500m in data centre, enterprise and campus networks. Unlike light-emitting diodes (LEDs), which emit light from the top and sides, and edge-emitting lasers, which emit light from the side of the chip once it has been cut, VCSELs emit a beam of light at right angles to the top of the chip. This means it is possible to test the optical properties of an individual device before the wafer has been cut up and packed into individual devices, thus improving yield. Additionally, IQE is the first company to have a process for producing 6” diameter VCSEL wafers. Having a higher diameter means that more devices can be manufactured at the same time, substantially reducing cost/device. These two factors significantly reduce the cost of production, potentially enabling arrays of VCSELs to be deployed in consumer electronics devices (including gaming devices, smartphones and tablets) for laser focusing, 3D imaging, proximity sensing and gesture recognition. The reduced cost also means that it is possible to create a two-dimensional array consisting of hundreds of individual sources that collectively output a high power beam tuned to a specific frequency. This has applications in industrial illumination, 3D printing, drying and curing plastics and sintering metals. IQE is currently engaged directly with a number of OEMs (as opposed to the more common chip/component vendor relationship) on projects relating to high-volume end-markets.

Telecommunications companies are increasingly deploying passive optical networks (PONs) to deliver triple-play services including TV, voice over IP (VoIP) phone and internet service to subscribers. These networks are also referred to as FFTH (fibre to the home), FFTP (fibre to the premises) or FTTC (fibre to the curb) networks. These optical networks can deliver the much higher data rates that are essential for distribution of video and other internet services. IQE has developed a novel technique for manufacturing distributed feedback (DFB) lasers used in these short-haul (up to 20km) networks. IQE has developed a proprietary technology that has enabled it to take on InP projects that previously customers had to manufacture themselves.

IQE is currently the dominant outsource provider of epitaxy for photonics applications. This position was recognised in FY15 when IQE was appointed as key partner in a new consortium to establish the US’s first Integrated Photonics Institute for Manufacturing Innovation, providing advanced epitaxy services to the 55 industrial partners.

IQE’s photonics revenues grew by 45% during H116 to £10.7m. The company is benefiting from underlying market growth and by component vendors transitioning from a vertically integrated business model towards outsourcing wafer supply from IQE. Around half of the revenues were from VCSELs, the other half InP epitaxy. Our estimates model H2 sectoral sales at similar levels to H116. In August 2016 industry analysts Grand View Research predicted that the global photonics market would grow from over $600bn in 2015 to c $980bn by 2024. Given the market outlook and strong pipeline, we model a 17% increase during FY17, which may be revised upwards as development programmes convert to volume deliveries. Wafer prices for photonic applications are an order of magnitude higher than for wireless applications, giving a highly beneficial impact on margins.

Compound semiconductors containing antimonides are used to manufacture emitters and detectors of light in the infrared part of the spectrum. Historically, this has been a high-margin business focused on defence applications such as night vision equipment. IQE is able to produce the industry’s first 6” indium antimonide wafers. The move to larger diameter wafers improves the economics of production. This permits the deployment of infrared chips in high-volume applications such as the measurement of environmental pollutants from industrial processes and automotive engines; non-invasive devices to monitor levels of oxygen, sugar or alcohol in the bloodstream; stand-off detection of explosives and biological threats; and specialised free space communication systems. In April 2016 IQE announced that it had joined a new consortium to create an end-to-end supply chain for a wide range of analytical micro-sensors based on the ability to emit and detect light in the mid-infrared part of the spectrum. The European Commission and the Swiss government are collectively investing €15m in the programme. IQE’s role will be to provide consortium partners and commercial customers with a volume source of epitaxial wafers.

Following the acquisition of Galaxy Compound Semiconductors in 2010, IQE is the largest supplier of infrared epitaxy globally, with almost an 80% market share. Sectoral revenues grew by 2% year-on-year during H116 to £4.7m. Our estimates model a modest 3% rise in sectoral sales during FY17. We believe faster FY17 growth is achievable given the potential expansion into consumer applications.

CPV (concentrated photovoltaic) solar cells use lenses or mirrors to concentrate light up to 1,000x onto a small area of semiconductor material. Compound semiconductor material is able to withstand the high temperatures involved better than silicon. Moreover, it is possible to tailor the compound semiconductor material to have multiple layers of different semiconductors, each tuned to absorb a different frequency of light and convert it to electricity. This means that a higher proportion of the incident light energy is converted to power than with conventional silicon-based solar cells.

IQE and its partner, Solar Junction, are currently focused on space applications of compound semiconductor technology. For these applications the weight constraints imposed by needing to launch satellites into orbit are more important than the relative economics of deploying compound semiconductor PV (more efficient but more expensive) versus conventional solar cells, which determine terrestrial deployments. The greater efficiency of compound semiconductor PV cells gives more power, and thus more capacity for data-transmission for the same weight payload. A leading satellite manufacturer is currently qualifying Solar Junction’s compound semiconductor PV modules to power satellites. We note that smartphone vendor Kyocera has demonstrated smartphones with integrated solar panels to extend time between battery charges. This application, where efficiency is paramount, may be a potential application area for compound semiconductor PV technology.

The partnership with Solar Junction is still being targeted to generate revenues from terrestrial applications in the longer term. Solar Junction was acquired by Taqnia, an investment vehicle of the Saudi government, in 2014. The technology is of interest to the Saudi government because low oil prices have caused a $120bn budget deficit (22% of GDP). Currently, a significant proportion of domestically produced oil is used in power generation, a proportion that is expected to increase as the kingdom industrialises to reduce its dependence on oil. Widespread utility-scale deployment of solar power would release oil for export and reduce diesel imports, which are subsidised by the government. Volume deployment of Solar Junction’s CPV modules in Saudi Arabia would fulfil several of the aims of the Saudi government’s Vision 2030 Programme: reducing oil subsidies; reducing environmental pollution; participating in emerging technologies; and improving employment opportunities.

Revenues from this sector were not material in H116, though ongoing development activities encourage management to expect good commercial progress in the next one to two years. Until IQE begins to ship meaningful volumes of the material, we will treat revenues from this sector as upside to our estimates.

Gallium nitride (GaN) compound semiconductor material is used for making power electronics chips because it can withstand higher voltages than silicon and is better at removing waste heat energy. Electric vehicles require high-performance power devices for their advanced power control systems, as do driverless vehicles for their highly complex sensor systems. However, GaN wafers are too expensive to be viable as a substrate material. In addition, it is currently not possible to manufacture compound semiconductor wafers with as large a diameter as silicon wafers. This means that fewer devices can be accommodated on each compound semiconductor wafer compared with a silicon wafer and that it is not possible to use efficient state-of-the-art silicon wafer handling equipment for compound semiconductor manufacturing, further increasing the relative cost compared with silicon. IQE is pioneering techniques that combine the cost-effectiveness of silicon with the enhanced properties of compound semiconductors by layering the compound semiconductor material on top of the silicon. This is not a trivial undertaking because the two materials have different crystalline lattice structures. In the absence of any intervention, the compound semiconductor layer is full of defects that degrade its electrical properties.

IQE began its development of compound semiconductor on silicon substrate in 2000, when it established the IQE silicon facility in Cardiff. The acquisition of NanoGaN in 2009 brought additional IP. In September 2015 IQE accelerated its development activity in this segment by acquiring exclusive rights to Translucent’s patented cREO (crystalline Rare Earth Oxide) technology. (Translucent is a subsidiary of ASX-listed Silex Systems.) This technique creates a buffer layer enabling GaN and other compound semiconductors to be deposited on silicon substrates in such a way that their electrical properties are not compromised. As discussed earlier, IQE intends to use this technology to recapture share in the wireless switch segment, as well as to strengthen its presence in the power electronics market. The technology has potential in all of IQE’s other key markets as well. A major milestone towards commercialising the material was reached in May 2016, when IQE announced that it had successfully transferred the cREO technology to its facility in North Carolina. The same month, IQE also announced a strategic partnership with imec, a world-leading nanoelectronics research centre, to continue the development of GaN-on-Si power devices.

Importantly, Translucent has 74 granted patents and 13 pending patents. The agreement not only accelerates IQE’s existing development programmes, but also secures IP rights, reducing the risk of IP disputes in the future.

Revenues attributable to the power semiconductor market are not material at present and are included in advanced electronics (CMOS++) revenues. Until IQE begins to ship meaningful volumes of the material, which management estimates is two to three years off, we will treat revenues from this sector as upside to our estimates. The GaN market is very attractive for IQE as it represents one of the largest growth opportunities for compound semiconductors. Market analyst Yole Développement has estimated the GaN power semiconductor device market to be worth around $10m in 2015 (note: the wafer market will be smaller), but forecasts that this will grow at an estimated 93% CAGR through 2016-20 to reach more than $300m in its baseline scenario. Infineon’s acquisition in July 2016 of Cree’s Power and RF and silicon carbide substrate businesses with the intention of extending its portfolio to include more efficient power electronics/power management devices for IoT applications as well as higher frequency RF devices emphasises the importance of compound semiconductors for delivering competitive advantage in this sector.

Together with a number of partners (including Intel), IQE’s CMOS++ (compound materials on silicon) business is developing technologies for creating hybrid integrated chips with areas of compound semiconductor material and traditional CMOS on a common silicon substrate. This would enable the creation of highly integrated devices combining a power amplifier in compound semiconductor with a filter and switch stack in CMOS. These developments are still in the research phase, although the Translucent acquisition has given the programme a substantial boost. Management expects this novel technology to deliver significant revenues over the next three to five years.

Licence income (6% H116 revenues)

Licence income, which totalled £3.5m in H116 (H115: nil), is a new revenue stream for IQE. At present it is generated from two JVs. The JV in Singapore is with WIN Semiconductors and Nanyang Technological University. The JV in Wales was formed in July 2015 with Cardiff University. Revenues are expected to be relatively lumpy. We expect FY16 licence revenues, which only include recurring elements, to be lower than FY15 revenues (£8.0m), which include upfront elements as well. We model FY17 licence income at FY16 levels. This additional revenue stream is likely to become more significant in the longer term if IQE’s technology is deployed in volume applications such as general-purpose LED lighting and solar power. The Translucent deal significantly boosts IQE’s ability to benefit from licensing fees because it gives access to an extensive patent portfolio, helping establish IQE’s rights to generate revenue from its IP.

Revenues increased by 18% year-on-year (£9.8m) during H116 to £63.0m. This resulted from modest growth in the wireless segment, strong growth in photonics and a contribution from licence income, which did not start generating revenues until H215. Adjusted gross margins rose by 4.2bp to 28.4%, reflecting a higher proportion of photonics revenues and licence income. Adjusted sales, general and administrative expenses grew by 17.0%, as management strengthened the engineering resource to provide capacity to support the anticipated growth in photonics and allocated labour to repurpose existing equipment for anticipated photonics production. In addition, while work on early-stage projects for customers yields a relatively high gross margin, it results in low utilisation rates because the equipment is used for very low volume runs. Adjusted profit before tax rose by 71% to £10.1m.

Our profitability model is based on a 50%+ contribution margin from product sales. This is different to gross margin because reported cost of goods includes both fixed and variable costs. The contribution margin varies depending on product mix, so we model it as increasing slightly during the forecast period to reflect the higher-margin photonics business. We model 7% total revenue growth in FY16 on the back of the recovery in wireless, which we expect to be partly offset by the absence of upfront licence fees that benefited FY15. The 5% revenue growth estimated for FY17 is primarily attributable to continued strong growth in photonics. We note the potential for stronger growth associated with the deployment of infrared sensors in consumer applications, penetration of the power electronics market and volume roll-out of CPV solar technology. The H116 results show that IQE is in good shape to achieve the revenue and profit growth shown in our estimates.

The improved profitability in H116, combined with a further reduction in the ongoing wafer discounts given to Qorvo (the merged RFMD/TriQuint entity), as deferred consideration for the RFMD epitaxy business, resulted in much stronger adjusted cash generation at the operating level (£13.0m vs £5.3m in H115). However, IQE still consumed cash during H116. Net debt increased by £10.4m to £33.6m (19.5% gearing). The main causes of this were: £10.7m final tranche of deferred consideration for Kopin; £2.8m capitalised development expenditure (higher than £2.1m in H115 because of the levels of photonic and other development activity); and £4.3m capex (£1.3m H115) as IQE invested in equipment modifications ahead of the anticipated ramp-up in photonics volumes.

Our estimates show net debt decreasing slightly during H216 to £30.5m at end FY16 (before the impact of any foreign currency retranslation). After FY16 the balance sheet will no longer be encumbered by any deferred consideration (£1.7m end June 2016). Cash conversion will improve as the last wafer discounts (estimated £5.5m payment in FY16) will be paid in H216. Following a long period of investment, capex, capitalised development costs and investment in other intangible fixed assets (£9.5m total) are expected to be less than D&A (£11.6m), so we estimate that the cash generated from operations will reduce net debt levels to £10.1m (6% gearing) at end FY17.

Peer multiples

Although the share price has rallied from a low of 16.25p in June, IQE’s rating still remains undemanding relative to its peers. We believe that a number of factors have contributed to this discount historically. These have included uncertainty over both the prospects for the wireless business and the timing and rate at which revenues in new non-wireless fields would grow. The company’s net debt and deferred consideration liability, and the suppressing effect on cash flows of the RFMD wafer discounts, have probably had an impact as well.

With regards to concerns about the wireless market, the interim results show that the destocking that bedevilled H215 is over and the market is growing again, albeit at a modest rate compared with five or six years ago. In addition, reliance on the wireless sector is reducing because of strong growth in photonics revenues and the creation of a new revenue stream from licence income. The announcement in the interims of another six months of strong growth in photonics gives reassurance that the contribution from this sector is here to stay. While there remains considerable uncertainty as to just how large revenues from this sector could become, our estimates treat the substantial growth that may result from existing photonics development programmes converting to volume deliveries as upside. As revenues from volume photonics projects, as well as material revenues from power electronics or advanced solar are excluded from our estimates, there is no reason to apply a discounted multiple to reflect downside risk to earnings from these sectors.

Examining the potential cash flow and balance sheet concerns, both of these disappear during H216. The RFMD wafer discount finishes in H216, improving cash conversion. The deferred consideration balance was eliminated in full by the end of September 2016.

As the reasons why investors have historically applied a discount have been removed, the share price has responded positively. However, our analysis of peer multiples indicates that there is still some way to go before IQE is trading on similar multiples to its listed peers. Our indicative valuation range of 40-45p puts IQE on multiples that are close to the mean of our sample. Further newsflow confirming photonics growth and stable wireless demand should help close the remaining valuation gap.

Exit multiples

For another approach to valuation we consider the prices paid to acquire peers. In calendar Q116 semiconductor laser specialist II-VI purchased IQE’s smaller competitor EpiWorks for 3.5x CY15 revenues (including deferred consideration). In March 2016 Chinese LED manufacturer Sanan Optoelectronics announced its intention to acquire compound semiconductor foundry Global Communication Semiconductors for 4.5x historical revenues. In July 2016 Infineon acquired Cree’s Power and RF business and associated silicon carbide wafer operations for 4.9x historical revenues. These transactions emphasise the value that the market is currently placing on companies that, like IQE, are rich in IP.
