Mineral resource estimate upgrade
Amur had a record field season in 2016, drilling 80 holes of 19,400.8m in aggregate length compared to a target of 15,000m. In so doing, the company confirmed the presence of continuous mineralisation along a 3,000m strike length at MKFL (cf 2,100m previously). Of the 59 (15,213.3m) resource definition holes, those intersecting ore grade mineralisation recorded an average mineralised thickness of 13.5m per interval, an average cumulative thickness of 23.6m per hole and an average length weighted grade of 0.76% Ni and 0.21% Cu (using a 0.2% nickel cut-off grade). In addition, the previously identified high grade structure (defined as >0.5% Ni) has been confirmed to exist along the entire 3,000m strike length of MKFL, with an average mineralised thickness of 10.5m per interval, an average cumulative thickness of 19.7m per hole and an average length weighted grade of 0.90% Ni and 0.25% Cu.
Of note is the fact that the headline grades of the holes drilled during the 2016 field season were higher both on average and specifically within the high grade domain than those recorded in the Kun-Manie May 2016 resource estimate. Cumulative widths in excess of 20m in the western extension of MKFL also compare with widths of c 12m elsewhere in the deposit. All MKFL drill identified mineralisation has now been conducted at a spacing deemed by SRK to be suitable for the definition of indicated resources.
On 10 February, Amur announced an updated mineral resource estimate, as compiled by consultants RPM. Unlike the previous resource estimate, dating from May 2016, which was calculated at a cut-off grade of 0% nickel, the new resource estimate was calculated at a cut-off grade of 0.4% Ni. As a result, sub-economic mineralisation is no longer included in the global resource inventory. A comparison between the January 2017 mineral resource estimate (at a cut-off grade of 0.4% Ni) and the May 2016 mineral resource (at a cut-off grade of 0% Ni) is as follows:
Exhibit 1: Kun-Manie mineral resource estimate, January 2017 vs May 2016 (0.4% cut-off grade, excluding Gorny)
|
January 2017 mineral resource estimate |
|
Change vs May 2016 mineral resource estimate (units)* |
Orebody |
Tonnage (Mt) |
Ni (%) |
Ni (t) |
Cu (%) |
Cu (t) |
Co (%) |
Co (t) |
Pt (g/t) |
Pt (t) |
Pd (g/t) |
Pd (t) |
|
Tonnage (Mt) |
Ni (%) |
Ni (t) |
Cu (%) |
Cu (t) |
Co (%) |
Co (t) |
Pt (g/t) |
Pt (t) |
Pd (g/t) |
Pd (t) |
Kubuk |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Measured |
0.0 |
0.00 |
0 |
0.00 |
0 |
0.000 |
0 |
0.00 |
0.0 |
0.00 |
0.0 |
|
0.0 |
0.00 |
0 |
0.00 |
0 |
0.000 |
0 |
0.00 |
0.0 |
0.00 |
0.0 |
Indicated |
3.6 |
0.87 |
31,320 |
0.21 |
7,560 |
0.016 |
576 |
0.18 |
0.6 |
0.19 |
0.7 |
|
-0.1 |
0.11 |
2,820 |
0.03 |
260 |
0.016 |
576 |
-0.02 |
-0.1 |
0.00 |
0.0 |
Total M&I |
3.6 |
0.87 |
31,320 |
0.21 |
7,560 |
0.016 |
576 |
0.18 |
0.6 |
0.19 |
0.7 |
|
-0.1 |
0.11 |
2,820 |
0.02 |
260 |
0.016 |
576 |
-0.02 |
-0.1 |
0.00 |
0.0 |
Inferred |
10.9 |
0.74 |
80,660 |
0.20 |
21,800 |
0.015 |
1,635 |
0.16 |
1.7 |
0.14 |
1.5 |
|
-11.1 |
0.28 |
-23,840 |
0.05 |
-10,300 |
0.015 |
1,635 |
0.02 |
-1.3 |
0.02 |
-1.2 |
Total |
14.5 |
0.77 |
111,980 |
0.20 |
29,360 |
0.015 |
2,211 |
0.16 |
2.4 |
0.15 |
2.2 |
|
-11.2 |
0.25 |
-21,020 |
0.05 |
-10,040 |
0.015 |
2,211 |
0.02 |
-1.4 |
0.02 |
-1.2 |
Ikenskoe |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Measured |
10.1 |
0.66 |
66,660 |
0.18 |
18,180 |
0.011 |
1,111 |
0.21 |
2.1 |
0.25 |
2.5 |
|
-7.4 |
0.15 |
-21,940 |
0.04 |
-6,020 |
0.011 |
1,111 |
0.03 |
-1.0 |
0.06 |
-0.9 |
Indicated |
6.3 |
0.61 |
38,430 |
0.14 |
8,820 |
0.011 |
693 |
0.20 |
1.3 |
0.25 |
1.6 |
|
-5.5 |
0.22 |
-7,570 |
0.04 |
-2,580 |
0.011 |
693 |
0.06 |
-0.4 |
0.09 |
-0.4 |
Total M&I |
16.4 |
0.64 |
105,090 |
0.16 |
27,000 |
0.011 |
1,804 |
0.21 |
3.4 |
0.25 |
4.1 |
|
-13.0 |
0.18 |
-29,610 |
0.04 |
-8,600 |
0.011 |
1,804 |
0.04 |
-1.5 |
0.06 |
-1.4 |
Inferred |
4.7 |
0.84 |
39,480 |
0.20 |
9,400 |
0.016 |
752 |
0.19 |
0.9 |
0.23 |
1.1 |
|
-1.2 |
0.06 |
-6,620 |
0.01 |
-2,000 |
0.016 |
752 |
0.00 |
-0.2 |
0.03 |
-0.1 |
Total |
21.1 |
0.69 |
144,570 |
0.17 |
36,400 |
0.012 |
2,556 |
0.20 |
4.3 |
0.25 |
5.2 |
|
-14.2 |
0.17 |
-36,230 |
0.04 |
-10,700 |
0.012 |
2,556 |
0.03 |
-1.6 |
0.06 |
-1.5 |
Vodorazdelny |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Measured |
0.6 |
0.74 |
4,440 |
0.22 |
1,320 |
0.012 |
72 |
0.29 |
0.2 |
0.32 |
0.2 |
|
-0.2 |
0.17 |
-260 |
0.05 |
-80 |
0.012 |
72 |
-0.01 |
0.0 |
0.02 |
0.0 |
Indicated |
3.2 |
0.85 |
27,200 |
0.21 |
6,720 |
0.017 |
544 |
0.16 |
0.5 |
0.16 |
0.5 |
|
-1.6 |
0.19 |
-4,000 |
0.04 |
-1,480 |
0.017 |
544 |
0.06 |
-0.1 |
0.06 |
-0.1 |
Total M&I |
3.8 |
0.83 |
31,640 |
0.21 |
8,040 |
0.016 |
616 |
0.18 |
0.7 |
0.19 |
0.7 |
|
-1.8 |
0.19 |
-4,260 |
0.04 |
-1,560 |
0.016 |
616 |
0.04 |
-0.1 |
0.04 |
-0.1 |
Inferred |
1.0 |
0.81 |
8,100 |
0.22 |
2,200 |
0.016 |
160 |
0.17 |
0.2 |
0.16 |
0.2 |
|
1.0 |
0.81 |
8,100 |
0.22 |
2,200 |
0.016 |
160 |
0.17 |
0.2 |
0.16 |
0.2 |
Total |
4.8 |
0.83 |
39,740 |
0.21 |
10,240 |
0.016 |
776 |
0.18 |
0.9 |
0.18 |
0.9 |
|
-0.8 |
0.19 |
3,840 |
0.04 |
640 |
0.016 |
776 |
0.04 |
0.1 |
0.04 |
0.1 |
Maly Kurumkon |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Measured |
0.0 |
0.00 |
0 |
0.00 |
0 |
0.000 |
0 |
0.00 |
0.0 |
0.00 |
0.0 |
|
0.0 |
0.00 |
0 |
0.00 |
0 |
0.000 |
0 |
0.00 |
0.0 |
0.00 |
0.0 |
Indicated |
57.5 |
0.77 |
442,750 |
0.22 |
126,500 |
0.015 |
8,625 |
0.15 |
8.6 |
0.16 |
9.2 |
|
-10.9 |
0.35 |
157,550 |
0.10 |
42,300 |
0.015 |
8,625 |
0.05 |
2.0 |
0.06 |
2.3 |
Total M&I |
57.5 |
0.77 |
442,750 |
0.22 |
126,500 |
0.015 |
8,625 |
0.15 |
8.6 |
0.16 |
9.2 |
|
-10.9 |
0.35 |
157,550 |
0.10 |
42,300 |
0.015 |
8,625 |
0.05 |
2.0 |
0.06 |
2.3 |
Inferred |
3.4 |
0.80 |
27,200 |
0.22 |
7,480 |
0.017 |
578 |
0.16 |
0.5 |
0.15 |
0.5 |
|
-18.8 |
0.43 |
-54,200 |
0.10 |
-18,120 |
0.017 |
578 |
0.06 |
-1.4 |
0.05 |
-1.5 |
Total |
60.9 |
0.77 |
469,950 |
0.22 |
133,980 |
0.015 |
9,203 |
0.15 |
9.2 |
0.16 |
9.7 |
|
-29.7 |
0.37 |
103,350 |
0.10 |
24,180 |
0.015 |
9,203 |
0.06 |
0.7 |
0.06 |
0.8 |
Total measured |
10.7 |
0.66 |
71,100 |
0.18 |
19,500 |
0.011 |
1,183 |
0.21 |
2.3 |
0.25 |
2.7 |
|
-7.6 |
0.15 |
-22,200 |
0.04 |
-6,100 |
0.011 |
1,183 |
0.03 |
-1.1 |
0.05 |
-1.0 |
Total indicated |
70.6 |
0.76 |
539,700 |
0.21 |
149,600 |
0.015 |
10,438 |
0.16 |
11.0 |
0.17 |
12.0 |
|
-18.1 |
0.32 |
148,800 |
0.10 |
38,500 |
0.015 |
10,438 |
0.05 |
1.5 |
0.05 |
1.7 |
Total M&I |
81.3 |
0.75 |
610,800 |
0.21 |
169,100 |
0.014 |
11,621 |
0.16 |
13.3 |
0.18 |
14.7 |
|
-25.7 |
0.30 |
126,700 |
0.08 |
32,500 |
0.014 |
11,621 |
0.04 |
0.3 |
0.05 |
0.7 |
Total inferred |
20.0 |
0.78 |
155,440 |
0.20 |
40,880 |
0.016 |
3,125 |
0.17 |
3.4 |
0.16 |
3.3 |
|
-30.1 |
0.21 |
-76,560 |
0.04 |
-28,320 |
0.016 |
3,125 |
0.05 |
-2.7 |
0.05 |
-2.6 |
Grand total |
101.3 |
0.76 |
766,240 |
0.21 |
209,980 |
0.015 |
14,746 |
0.16 |
16.7 |
0.18 |
18.0 |
|
-55.8 |
0.28 |
50,040 |
0.07 |
4,080 |
0.015 |
14,746 |
0.04 |
-2.4 |
0.05 |
-1.9 |
Source: Amur Minerals, Edison Investment Research. Note: *Totals compare to May 2016 mineral resource estimate reconfigured to exclude Gorny; M&I = Measured and Indicated. Totals may not add up owing to rounding.
Of note, within this context, is the material increase in the resource at Maly Kurumkon, as a result of the exploration conducted during the 2016 field season and despite the increase in the cut-off grade. This contrasts with three other deposits (Vodorazdelny, Ikenskoe and Kubuk), at which no additional drilling has been conducted since May 2016 and at which the changes in resources therefore only reflected a recalculation based on a higher cut-off grade. As expected, in these cases, the higher cut-off grade resulted in a decline in the overall ore tonnage, an increase in the in-situ grade of nickel and a proportionately smaller decline in the number of contained nickel tonnes. One interpretation of the 2016 field season therefore is that it has more than replaced hitherto sub-economic resources with economic ones. Note that no recalculation was performed at Gorny, which is a relatively small deposit and the only one with an average grade below the 0.4% cut-off grade at the time of the H116 mineral resource estimate. As a result, Gorny has been excluded from the above table, although future drilling may result in its re-inclusion once again, at a later date.
Nevertheless, direct comparison may be made between three deposits, for which a range of resource estimates were provided at varying cut-off grades (including 0.4% Ni) in Q216:
Exhibit 2: Total resource increase, by area, constant 0.4% cut-off grade
|
January 2017 total resource |
|
Change vs May 2016 (units) |
|
Change vs May 2016 (%) |
|
Tonnage (Mt) |
Grade Ni (%) |
Contained Ni (t) |
|
Tonnage (Mt) |
Grade Ni (%) |
Contained Ni (t) |
|
Tonnage (%) |
Grade Ni (%) |
Contained Ni (%) |
Kubuk |
14.5 |
0.77 |
111,980 |
|
1.0 |
0.06 |
16,480 |
|
7.4 |
8.8 |
17.3 |
Ikenskoe |
21.1 |
0.69 |
144,570 |
|
3.4 |
-0.12 |
1,970 |
|
19.2 |
-15.4 |
1.4 |
Maly Kurumkon |
60.9 |
0.77 |
469,950 |
|
27.9 |
-0.06 |
195,250 |
|
84.5 |
-7.0 |
71.1 |
Sub-total |
96.5 |
0.75 |
726,500 |
|
32.3 |
-0.05 |
213,700 |
|
50.3 |
-5.7 |
41.7 |
Source: Amur Minerals, Edison Investment Research
As such, whereas the headline increase in resources (Exhibit 1) is 50,040t (+6.8% including Gorny or +10.3% excluding Gorny from May 2016 estimate) of contained nickel, compared to the previous resource, once the change in cut-off grades is taken into account, the underlying like-for-like change is 213,700t, or 41.7%, of contained nickel. Of note, once again, is the disproportionate increase in the resource at Maly Kurumkon on account of the exploration work performed in 2016, compared to the three other deposits, as a result of which it now comprises 61% of the Kun-Manie resource (cf 50% previously):
Exhibit 3: Kun-Manie resource by area, January 2017
|
Exhibit 4: Kun-Manie resource by area, May 2016
|
|
|
Source: Amur Minerals, Edison Investment Research
|
Source: Amur Minerals, Edison Investment Research
|
Exhibit 3: Kun-Manie resource by area, January 2017
|
|
Source: Amur Minerals, Edison Investment Research
|
Exhibit 4: Kun-Manie resource by area, May 2016
|
|
Source: Amur Minerals, Edison Investment Research
|
In nickel and gold (as an illustrative exercise) equivalent, Amur’s total mineral resource can therefore be stated as follows (at prevailing metals’ prices at the time of writing):
Exhibit 5: Kun-Manie total mineral resource estimate, nickel and gold equivalent
|
Tonnage (Mt) |
Grade |
Contained metal |
Nickel equivalent |
101.3 |
1.03% NiE |
1.0Mt |
Gold equivalent |
101.3 |
2.86g/t AuE |
9.3Moz |
Source: Edison Investment Research, Amur Minerals
Based on our end-FY16 cash estimate, Edison estimates an enterprise value for Amur of US$56.3m, which equates to US$73.47 per total nickel resource tonne. That being the case, a headline resource increase of 50.0kt Ni should have added US$3.7m in (pro rata) value to Amur, while a like-for-like increase of 213.7kt should have added US$15.7m – compared to an estimated cost of the associated drilling of c US$1.3m (being 15,213.3m of resource definition drilling at management’s all-in estimate of drilling costs of US$75-100 per metre drilled).
The forthcoming 2017 field season
After a 2016 field season focused on MKFL, Amur is now targeting Kubuk in the forthcoming 2017 field season. The existing Kubuk resource is contained within a 1km strike length.
Exhibit 6: The five currently defined exploration areas at Kun-Manie
|
|
|
Currently, 10,000m of drilling is planned in the area of the existing resource to upgrade a 10.9Mt inferred resource block into the indicated category (similar to MKFL drilling in the 2016 field season). The inferred block is currently the largest single continuous block of inferred resources within Kun-Manie and will account for c 6,000m of (in-fill) drilling by the company’s LF90 drill rig working at depths typically exceeding 200m. In addition, a minimum of seven metallurgical holes are planned, totalling a further 1,500-2,000m. The remaining c 1,000m will then be conducted as 1) step-out drilling over an additional 1km of strike length extension to the east of the existing resource and 2) to the west of the existing resource area in the 3km gap between Ikenskoe-Sobolevsky and Kubuk in an initiative to prove continuity between the two. NB In the event of continuity, this is likely to prove the deepest part of the orebody within Amur’s licence area.
A total of 5,000m of drilling are also planned for Amur’s LF70 drill rig at Ikenskoe-Sobolevsky (where holes are typically shallower – eg less than 200m). Approximately 2,000-2,500m is planned for completion on the Sobolevsky part of the deposit, located to the south and east of the currently defined drill identified mineralisation, with the objective of expanding the resource in the direction of Kubuk. As at Kubuk, additional drilling will also be completed to generate a metallurgical sample for this deposit.
Beyond the availability of water from the Maya River, Amur plans to complete six to eight holes to establish potential sources of groundwater for industrial use to process the ore. Finally, drilling will also be completed at Maly Kurumkon-Flangovy to establish potential water inflow rates within the planned open pits and underground operations in order to establish dewatering requirements for the mine.
Inevitably, the amount of drilling completed will be weather dependent. Typically, c 15,000m of drilling can be completed by two drill rigs in four to five months. However, sufficient supplies have been procured to support 20,000m of drilling, should the opportunity for an extended season present itself. Additional equipment purchased to facilitate the completion of work necessary for the ongoing development of Kun-Manie includes a 25t truck mounted crane, a Caterpillar 320D2L excavator, a Caterpillar D6RII bulldozer, a water well drilling truck, Ural trucks (for fuel, drop side loading and personnel transport), portable cabins, drill water pumps and additional power generators at cost of c US$1.04m.
At an average cost of US$40/m for drilling alone, this 15,000m programme is anticipated to have a total direct cost of c US$0.6m.
The 2017 field season is anticipated to conclude the major period of Amur’s exploration activity. In due course, Amur intends to explore the 900m gap between the MKFL and Gorny ore-bodies (of which 400m lies on the easternmost side of the MKFL area and 500m lies within the Gorny area). If drilling of these extensions proves successful (ie intersects mineralisation), Amur believes that it is possible that the MKFL and Gorny deposits will prove to be one larger deposit with a strike length of up to 5km.
